Stubby Brick Ties (L-Shaped)
Stubby Brick Ties (L-Shaped) are purpose-built for brick veneer walls where the cavity is too narrow for a standard tie.
At 100mm x 35mm in a right-angle profile, these ties are face-fixed to the frame before the brickwork reaches that height, then embedded in the mortar bed as the course is laid.
They comply with AS/NZS 2699-2000 for cavity wall tie performance and are available in galvanised (light duty and medium duty) and stainless steel options.
Supplied in boxes of 150 pieces, Stubby Brick Ties are ready to go straight from the box on site.
Since 1957, Vincent Buda and Company has stocked the full range of wall ties for Sydney builders.
Vincent Buda and Company stocks Stubby Brick Ties for same-day or next-day delivery within the Sydney Metro. Courier delivery available Australia-wide.
Product Specifications
- Material: Hot-dip galvanised steel (light duty or medium duty) or stainless steel
- Standard: AS/NZS 2699-2000 (wall ties for masonry construction)
- Shape: L-shaped (right angle)
- Dimensions: 100mm x 35mm
- Finish: Galvanised zinc or stainless steel
- Packing: 150 pieces per box
- Product Drawings: See Product Drawings
Key Features at a Glance
- Built for Thin Cavities: The short 35mm horizontal leg suits walls where stud-to-brick clearance is tighter than standard ties allow.
- AS/NZS 2699-2000 Compliant: Suitable for residential and light commercial brick veneer construction.
- Face-Fix Installation: Screw-fix to timber or steel framing before brickwork rises, then embed into the mortar bed as construction progresses.
- Galvanised or Stainless Steel: Choose galvanised for standard conditions or stainless steel for coastal and high-exposure environments.
Primary Applications
- Thin Cavity Brick Veneer: Ideal where standard wall ties are too long for the cavity width.
- Residential Brick Veneer Construction: Suitable for timber and steel stud brick veneer walls.
- Renovation and Infill Walls: Useful for retrofit work and walls with restricted cavity access.
- Coastal and High-Exposure Sites: Stainless steel option provides added corrosion resistance in harsh environments.
Pick-Ups
All stocked items are available for pickup within 2 working hours of placing your order.
Unsure if your items are in stock? Call us on (02) 9740 1500 before ordering to confirm availability.
Sydney Metro Deliveries
Courier Deliveries (Australia-Wide)
Direct-to-Door & Business-to-Business: Your goods will be unloaded using professional equipment and placed in a safe, accessible location at your destination.
Depot Delivery: Your order will be delivered to a Logistics Depot closest to your location. For details about your nearest depot, contact us on (02) 9740 1500 or sales@buda.com.au.
A1: It depends on your cavity width.
Stubby Ties work best for narrow cavities. At 100mm × 35mm, they fit tight stud-to-brick veneer situations without protruding past the brick face.
Frame Ties are better for larger cavities (over 50mm), extending further to span the additional distance.
Browse all wall ties in the Building Supplies collection.
For steel studs, use a suitable self-drilling metal screw. For timber framing, use a standard batten screw. The tie is then embedded into the mortar bed as brickwork is laid.
A3: Yes, they comply with AS/NZS 2699-2000.
Your structural engineer or BCA assessment will specify the tie spacing required for your wind classification zone. Compliance with AS/NZS 2699-2000 means these ties meet the Australian standard for brick veneer wall ties.
A4: Each box contains 150 pieces and is stocked now at Vincent Buda and Company.
Same-day or next-day delivery is available within the Sydney Metro. Courier delivery is available Australia-wide.
