Steel T-Bars, T-Beams & T-Section Lintels
2 products
2 products
T-Bars are the ultimate solution for supporting two skins of brickwork, providing a solid platform for both the internal and external skins in a single structural member. At Vincent Buda and Company, our T-Bar collection features our traditional beams as well as our innovative, patented Maxi T-Bar. The Maxi T-Bar is engineered with a solid 40x40mm billet for unmatched strength, and its 250mm wide base is designed to cover the cavity as it supports the brickwork either side. All our T-Bars are Hot-Dip Galvanised (R3) to ensure they remain durable and structural for the life of your home. Since 1957, we have been the primary choice for Australian builders tackling wide spans like garage doors and sliding patio entries. We know you need the steel to keep the project moving; that’s why we offer same-day or next-day delivery within the Sydney Metro on our entire T-Bar range.
Four Primary Applications for T-Bars:
Double Garage Spans: Providing heavy-duty structural support over wide openings.
Cavity Wall Windows: Supporting both brick skins simultaneously for a clean finish.
Patio & Sliding Doors: Providing a level, high-load support for large-span glass doors.
Structural Lintels: Used in any double-skin wall where high rigidity is required.
Why choose our T-Bars?
Unmatched Strength: Patented Maxi T-Bar design offers superior structural stiffness.
Permanent Finish: Hot-dip galvanised (R3) to prevent rust expansion inside the wall.
Easy to Install: Easy-to-use profiles that save time and labour on-site.
Fast Delivery: We deliver orders the same day or the next day within the Sydney Metro to keep your job moving.
Resources
FREQUENTLY ASKED QUESTIONS
It is significantly stronger and designed specifically for cavity walls. The solid billet design provides greater resistance to bending, making it ideal for larger spans. The wider base profile is engineered to suit a 270mm thick wall with a 50mm cavity, allowing both skins of brickwork to be supported correctly while maintaining the required cavity separation. The Maxi T-Bar should only be used in 270mm cavity brick walls. It is not suitable for solid 230mm walls, where a traditional T-Bar is required.
Yes, they are fully compliant with AS2699.3 and AS4100. Our T-Bars are engineer-tested to ensure they meet the structural requirements of your project.
As a rough guide add 300mm to your total opening width. This ensures you have the standard 150mm "bearing" on each side of the opening to distribute the load safely. If you are unsure, double-check with your engineer; they can tell you the length required for your application.
We offer same day or next day delivery within Sydney Metro. Vincent Buda and Company understands that you can't build up until the T-Bar is in, so we dispatch our stock immediately.
